[AWS Architect] (39) EBS Snapshots

A snapshot is a point-in-time backup of an ESB Volume stored in S3.

  • To protect against AZ failure, EBS snapshots (to S3) can be used.
  • Snapshots are incremental. The initial snapshot is a full copy, and future ones only store the data changed since the last snapshot, which can reduce the storage cost.
  • You can take a snapshot while the instance is running. When you back up a root volume, you need to stop the instance for data integrity.
  • You can create an AMI from a snapshot.
  • EBS volumes are in the same AZ of the EC2 instance.
Continue reading “[AWS Architect] (39) EBS Snapshots”

[AWS Architect] (36) Elastic File System (EFS)

Elastic File System (EFS) is a scalable managed service that implements the Network File System (NFSv4).

  • File systems can be mounted on multiple Linux instances at the same time. -> shared media, home folder, shared documents.
  • It can be accessed in the VPC, across the VPC, and even from outside of VPC through Direct Connect.
  • EFS is built to scale while maintaining low latency and high throughput. It can support thousands of current NFS connections.
  • EFS is a regional service that stores data across multiple AZs for high availability and durability.
  • EFS supports Read after Write consistency.
Continue reading “[AWS Architect] (36) Elastic File System (EFS)”

[AWS Architect] (35) Elastic Block Store (EBS)

Elastic Block Store (EBS) is a network-attached storage service that creates and manages persistent volumes.

  • Volumes are persistent (removed and attached) and are replicated within a single AZ.
  • You can change the EBS volume size and the storage type on the fly.
  • EBS supports a maximum per-instance throughput of 1,750 MiB/s.
  • EBS supports 80,000 IOPS per instance or 64,000 IOPS per volume.
  • By default, EBS volumes are replicated within the AZ.
Continue reading “[AWS Architect] (35) Elastic Block Store (EBS)”

[AWS Architect] (34) EC2 – Storages

  • Every EC2 instance must have a root volume, which may or may not be EBS (Elastic Block Store).
  • By default, an EBS root volume will be deleted when the instance is terminated. You can change the setting to make EBS volumes persistent.
  • You can attach additional EBS volumes to instances, and they are not deleted when the instance is terminated.
Continue reading “[AWS Architect] (34) EC2 – Storages”
